Technical Parameter
Model
H2015
H2515
H3015
H3020
H4020
H4025
Max Cutting Size
1900×1400
2400×1400
2900×1400
2900×1900
3900×1900
3900×2400
Z Axis Stroke
100mm
Structure
Gantry
Lubrication Mode
Oil Immersed
Processing Mounting Surface
Gantry Milling Machine
Control Accuracy
±0.01mm
Intensifier Assembly
ZL 2017 21116875.3
Patented Intensifier Assembly
Cooling method
Double Cooling Structure
Intensifier Inlet Water Pressure
＞0.4Mpa
Main Motor Power
22KW
Maximum Pressure
450MPa
Working Pressure
300-380MPa
Maximum Water Flow
3.7
Maximum Nozzle Diameter
0.33
Repeat Positioning Accuracy
±0.05mm
Cutting Accuracy
±0.1mm
Max Traverse Speed
10000mm/min
